DPP-Line systems

DPP-70

5 chambers, steel reinforced frame and sash construction. Argon filled insulated glass. Several hardware options allows for micro-ventilation, tilt and turn operation, anti-burglary hardware in every sash, concealed hinges available.


PROFILE

  • 5-chamber profile, 2-3/4” Frame Depth
  • Full steel in frame
  • Two retractable seals

  • GLASS

  • Dual Pane Glass (4x16x4)-Standard
  • U glass= 1.0 Wm2K (Comparable to: U-Value=.18)
  • Filled with Argon gas

  • HARDWARE

  • Microventilation
  • Anti-burglary catches in RU sashes
  • 4-stages tilting mechanism

  • HANDLE

  • Made of aluminium
  • Ergonomic shape
  • High durability

  • GLASS OPTIONS

    Warmth and extra lighting

    Triple Pane Glass (4x18x4x18x4)

  • Total solar energy transmittance: g=50% (Comparable to Solar Heat Gain Coefficient)
  • Light transmittance: L=70%
  • Thermal permeability: Ug=0.5 W/m2K (Comparable to U-Value=.09)

  • Security

    3-glass packet 44.4/14/4/14/4

    It is characterised by high impact resistance. Additionally, it is equipped with a filter protecting against high-energy fractions of sunlight and UV radiation.

  • Safety class: P4
  • Total solar energy transmittance: g=45%
  • Light transmittance: Lt=69%
  • Thermal permeability: Ug= 0,6 W/m2K

  • Warmth and Security

    3-glass packet 4/14/4/14/33.1

    Internal glass is covered by foil therefore broken glass does not disintegrate what excludes the risk of injury.

  • Safety class: B2B
  • Total solar energy transmittance: g=47%
  • Light transmittance: Lt=70%
    Thermal permeability: Ug= 0,6 W/m2K

  • Silence and Security

    3-glass packet 44.2/12/6/12/6

    Glass construction ensures a high level of protection against burglary and increased acoustic insulation.

  • Safety class: P2
  • Acoustic insulation coefficient: strong>Rw=39dB
  • Thermal permeability: Ug= 0,7 W/m2K

  • Maximum energy saving

    4-glass packet 4/12/4/12/4/12/4

    Three chambers of 4-glass packet guarantee the maximum thermal insulation making that the packet is an ideal product for passive houses.

  • Thermal permeability: Ug = 0,3 W/m2K
  • Total solar energy transmittance: g=33%
  • Light transmittance: Lt= 48%

  • HARDWARE

    ActivPilot SELECT hardware

    Hardware equipment

    When the sash is closed the hinges are invisible what gives the windows exceptionally elegant appearance and facilitates keeping the windows clean. A great advantage of the hardware is an easy regulation without using the tools.

  • Microventilation
  • Anti-burglary mushroom head locking devices
  • 2 anti-burglary catches in every RU sash
  • Handle rotation blockade with sliding

  • ActivPilot Comfort hardware

    Hardware equipment

    The system enables the sash from the frame at a distance of 6 mm to be disengaged what ensures efficient ventilation without cooling the interior suddenly. During ventilation the fitting has an increased level of protection against burglary and the vertical position of the handle does not show that the window is unsealed. The sash maintains a stable position under wind pressure and the slot dimensions allow the interior to be ventilated during the rain.

  • Slot ventilation system
  • 4 anti-burglary catches in every RU sash
  • Possibility to increase the number of catches

  • ActivPilot TILTFIRST hardware

    Hardware equipment

    The handle set horizontally tilts the window; full opening requires the handle to be set vertically. In connection with the TBT handle it allows the possibility to open the sash to be limited. Without the key it can be only tilted what eliminates the risk of falling out.

  • Microventilation
  • Anti-burglary mushroom head locking devices
  • Anti-burglary catch in every RU sash
  • Possibility to increase the number of catches
  • Handle rotation blockade with sliding

  • HANDLES


    1006

    1007

    1009

    1012

    1030

    Luksemburg

    New York

    1006D

    1006A

    Luksemburg

    HANDLES COLORS


    White

    Brown

    Silver Matte

    Old Gold

    Champagne

    Titanium


    Cross Sections


    PVC DPP70 WHITE

    PVC DPP70 GRAY

    PVC DPP70 BLACK-WHITE


    PVC DPP70 BLACK

    PVC DPP70 WOODGRAIN

    ALUMINUM DA70



    PVC Patio Doors

    HST lift-sliding door

  • Innovative lift and slide hardware system allows for smooth and effortless sliding panel movement.
  • Hardware allows for exceptionally large glass panel openings.
  • Doors have flush thresholds.

  • HKS tilt-sliding door


    Aluminium Patio Doors

    Bi-folding aluminium doors

    The folding door is an exceptional product that provides classic functionality.
    The folding system is a proven solution allowing full light transmission through the opened door. Regular vertical divisions give the interior and facade a stylish character.


    DA-75FD

    DA-75FD

  • Maximum transmission of light
  • Possibility of folding all sashes along the side edge
  • Two ways of opening: outwards inwards
  • Uw for construction (4000 mm x 2100 mm): 1,7 W/m2K
  • Maximum dimensions* of sash (width) 1000 mm

  • Sliding aluminium doors

    DA-77 HST

    Innovative lift-sliding doors with an improved thermal insulation and increased range of available glazing.
    Doors working on the basis of innovative lift-and-slide opening system, which gently lifts the sash moving on special rollers. As a result, sliding the doors do not require any effort.Door threshold can be faced with the floor level .The system allows to build large glazed surfaces with maximum interior lighting,which gives a very prestigious character.


    DA-77 HST

    DA-77 HST (corner door)
  • The maximum prestige and elegance
  • Easy opening and closing
  • The ability of facing treshold with the floor
  • Ability to perform the corner doors with movable post
  • Solution for a harmonious combination the interior of house with a balcony, terrace or open space
  • The maximum* sash dimensions 3300mm x 3200mm
  • Uw for construction (2460mm x 2180mm): 1,1W/m2K

  • DA-51 ST

    Sliding door system of high functionality. Construction possibilities allow to create glazing of large dimensions and threshold flush aligned eleminates an obstacle on the route. This product is a good solution for unheated interiors, glazed terraces, porches, restaurants or in case of restricted height of constructions.)

    Large constructions are created on the basis of frames with 1, 2 or 3 tracks with usage of even 6 sashes. Possibility to use monorail construction solutions which do not require the windowpanes to be put in the sashes of fixed surface (windowpanes are placed in frame). Narrow 34 mm compounds of sash and frame provide the interior with more natural daylight.)


    DA-51 ST

    DA-51 ST
  • Optimal solution for the development of terrace or porch
  • Possibility to realise glazing of large dimensions and lightweight constructions
  • Good parameters of thermal insulation:
  • Ud of reference construction (2460 mm x 2180 mm): 1,4 W/m2K
  • Easy door operation:
  • Max. *sash dimensions: 2600 mm x 2800 mm
  • Narrow compounds of sash and frame providing better lighting of the interior

  • HKS

    Full functionality and operational comfort of the door stem from the possibility to slide and tilt the movable sash easily.

    The system operation simplicity allows very advantageous prices to be achieved, therefore the elegant and trendy large glazing can be available to every home.


    HKS
  • The possibility of tilting the moving wings
  • Very attractive price
  • Maximum dimensions* for sash 1480 mm x 2330 mm

  • DA-40 ST


    DA-40 ST

    DA-40 ST
  • Smooth door operation
  • Maximum dimensions* for sash: 2000 mm x 2550 mm
  • Uw for construction (2460 mm x 2180 mm): 1,7 W/m2K


  • Wood Front Doors

    Meranti wood from Asia is used by DAKO to build high quality exterior wood doors.


    Galla

    Alma

    Kora

    Mela

    Canis

    Tulia

    Caura

    Tala

    Tulia

    *for more information and styles, please visit our location.



    PVC Front Doors

    Insulated with PVC core, low profile sill, aluminum clad front entry doors.


    Kenna

    Arianna

    Georgia

    Celia

    Galia

    Amadea

    *for more information and styles, please visit our location.



    PVC Panel Doors


    Caura

    Meva

    Bona

    Andrea

    Aurea

    Melisa

    Zola

    Felix

    Dalia

    Niceta

    Zoe

    Ofelia

    *for more information and styles, please visit our location.



    Blinds


    Blind are great solution for window treatment and interior decor. Wide selection of blinds from DAKO allows for choices in styles, colors, textures and sun blockage.

    Installation Possibilities


    Vertical Window

    Roof Window

    Lateral Rail
